Chapter 2 • The X-431 Scanner Components
2-4 ©X-431 USA
Connectors
There are several connectors that are included with the X-431. Many of them
are designed for specific vehicle lines,
such as the 38-pin connector for Mercedes-Benz
or the 20-pin connector for BMW.
The connectors that are included are:
• Toyota -17 • Nissan-14+16
• Mitsubishi/Hyundai-12+16 • Mazda-17
• Honda-3 • Mercedes Benz-38
• Kia-20 • GM/Daewoo-12
• BMW-20 • Chrysler-6
• Ford-6+1 • Smart OBDII-16 (General use
for Honda vehicles only)
• OBDII -16C • Fiat-3
•Universal-3 •BMW-16
• Audi/VW-4 • Daewoo
• Toyota-16 • CAN Connector
• Toyota -17F (22F) • Volvo CAN Connector
