2 • The X-431 Scanner

Components

The main console of the X-431 is composed of three separate pieces: the

Main Unit, the Mini-Printer, and the Smartbox. The following diagram

displays the main console and many of the connectors.

1 • X-431 Main

Unit

2 • Mini-Printer

3 • CF Card

4 • Diagnostic

Connector

5•Power

Converting

Cable

6•Cigarette

Lighter

Cable

7•Battery

Cable With

Single Clip

8•Power

Adapter

9 • Main Cable

10 • Smartbox
