Chapter 2 • The X-431 Scanner Be Careful
2-6 ©X-431 USA
User’s Manual
The User’s Manual is written in eleven languages and contains basic
information about using the X-431.
Be Careful
The X-431 is durably constructed, but a level of care should be taken with its
use. Be especially careful with the connectors and cables. The pins on these
objects are delicate and can bend or break. Never force a connector or a
cable into a port.
Special attention should be given to the CF Card.
• Always eject the CF Card completely before taking the leather case off,
because it is possible to damage the ejector lever when removing the case.
• Always eject the CF Card from your PC properly (see “Ejecting the CF
Card” on page 4-19 for instructions).
• Never pull the CF Card out if the unit is on.
• Never force the CF Card into the Reader or the Unit.
Security Features
The Smartbox component of the X-431 has a 12-digit serial number assigned
to it by Launch. When the unit is registered by the owner on
www.x431.com, this serial number is coupled with the username and
password that the owner inputs. Updates downloaded using that username
and password will only work with the associated Smartbox. The CF Card is
formatted with the serial number too, and so it will only work in conjunction
with the correct Smartbox, username, and password.
Printer Operation - Replacing Paper
The MiniPrinter uses heat sensitive, 30 X 57mm (7mm core) thermal paper.
To mount the printer paper, follow the procedure outlined below:
1. Open the paper lid on the back of the printer
2. Remove the spindle and mount the paper scroll onto the spindle.
