5. OBD-CAN
OBD-CAN can test engine systems according OBD-II and EOBD2 ISO15765-4(CAN) Standard, and the
functions are: read trouble code, clear trouble code, read dynamic data stream, read freezing frame and
readiness test.
Other CAN-Bus Systems
1. VW Vehicles: Diagnostic functions of all systems are being expanded. The Golf 5, Audi A8 4.2L use
the CAN-Bus system and all systems of these models can be used with CAN-Bus diagnostic communica-
tions mode.
2. Volvo Vehicles: Systems of almost all model years use the CAN-Bus diagnostic system, especially the
S80, S60, and XC90. CAN-Bus diagnosis of these models are different then general OBD-CAN diagnosis
and requires the use of special Volvo CAN connectors.
3. Nissan Vehicles: BCM and IPDM are being developed.
Chassis Identification Charts
The following pages show the chassis identification charts for Mercedex-Benz and BMW from 1988
through MY 2005.
MERCEDES-
BENZ
1988 1989 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005
E320 WAGON
124 124 210.265 210.265 210.265 210.265 210.265 211.265 211.265 211.265
E320 CDI
211.026
E420
124 124 210
E430
210.070 210.070 210.070 210.070 210.070
E430 4MATIC
210.083 210.083 210.083
E500
124 211.070 211.070 211.070
E500 4MATIC
SEDAN
211.083 211.083
E500 4MATIC
WAGON
211.283 211.283
E55 AMG
210.074 210.074 210.074 210.074 211.076 211.076 211.076
G500
463.249 463.249 463.249 463.249
G55 AMG
463.246 463.246 463.246
ML320
163.154 163.154 163.154 163.154 163.154
ML350
163.157 163.157 163.157
ML430
163.172 163.172
ML500
163.175 163.175 163.175 163.175
ML55 AMG
163.174 163.174 163.174 163.174
S320
140 140 140 140 140
S320 LWB
140
S320 SEDAN
140
S320 SEDAN
LWB
140
S350
140 140
S420
140 140 140 140 140 140
S430
220.170 220.170 220.170 220.170 220.170 220.170
S430 4MATIC
220.183 221.183 221.183
S500
140 220.175 220.175 220.175 220.175 220.175 220.175
S500 4MATIC
220.184 220.184 220.184
S55 AMG
220.173 220.173 220.174 220.174 220.174
S600
140 220.178 220.178 220.176 220.176 220.176
S500 COUPE
140 140 140 140
S500 SEDAN
140 140 140 140 140
S600 COUPE
140 140 140 140
S600 SEDAN
140 140 140 140 140
SL320
129 129 129 129
SL500
129 129 129 129 129 129 129.068 129.068 129.068 230.475 230.475 230.475
SL55 AMG
230.474 230.474 230.474
SL600
129 129 129 129 129 129 129.076 129.076 129.076 230.476 230.476
SL65 AMG
230.479
SLK230
170.447 170.447 170.447 170.449 170.449 170.449 170.449
SLK32 AMG
170.466 170.466 170.466
SLK320
170.465 170.465 170.465 170.465
SLK350
171.456
SLK55 AMG
171.473
