HGM1790N Genset Controller User Manual Page 21 of 31
7.2 DEFINABLE CONTENTS OF RELAY OUTPUTS
Table 8 Definable Contents of Relay Outputs
No.
Items
Description
0
Not Used
Output is not active.
1
Common
Alarm
Includes all shutdown alarms and warning alarms. Warning alarms are
not self-latching, while shutdown alarms are self-latching and will not
disappear until they are reset.
2
Energize to
Stop
Suitable for the genset with stop electromagnet. The electromagnet
closes when stop idle is over. And opens when EST delay is over.
3
Idle Control
Used for machines that have idles. Closes during cranking, disconnects
during warming up, closes during stop idle delay, disconnects after
complete stop.
4
Preheat
Control
It closes before starting and opens before starter is powered on.
5
Closing Gens
During normal operation of the generator, closes the breaker.
6
High Speed
Output
Output when entering high speed warming up and disconnect after high
speed cooling.
7
Reserved
8
Reserved
9
Reserved
7.3 DEFINABLE CONTENTS OF DIGITAL INPUTS
Table 9 Definable Contents of Digital Inputs (Active When GND (B-) Connected)
No.
Description
Notes
0
Not Used
1
High Temperature Alarm
If these signals are activated after crank disconnect,
shutdown alarm will be immediately initiated.
2
Low OP Alarm
3
Reserved
Only warning and not stops if this input is active.
4
Auxiliary Shutdown
Shutdown alarm will be immediately initiated if this input
is active.
5
High Temperature Cooling
Shutdown
When the genset is working normally and this signal is
activate, if there is a high temperature situation, the
controller will first cool down the generator and then stop
it; if the signal is deactivated and a high temperature
situation occurs, the controller will shut down the genset
without cooling down.
6
Reserved
7
Reserved
8
Multiplex Level Sensor
Parameter P44 ”Fuel Level Sensor” Input is active.
