Smartgen HGM1790N User Manual

HGM1790N Genset Controller User Manual Page 6 of 31
3. SPECIFICATION
Table 2 Technical Parameters
Item
Content
Working Voltage
DC8. 0V to 35. 0V, Continuous Power Supply
Power Consumption
<1.2W (Standby mode: ≤0.5W)
Alternator Voltage Input
AC 15V ~ AC 360 V (ph-N)
Alternator Frequency
50Hz/60Hz
Speed Sensor Voltage
1.0V to 24V (RMS)
Speed Sensor Frequency
Max. 10, 000Hz
Start Relay Output
1Amp DC28V DC B+ power supply
Fuel Relay Output
1Amp DC28V DC B+ power supply
Aux. Output1
1Amp DC28V DC B+ power supply
Aux. Output2
1Amp DC28V DC B+ power supply
Aux. Output3
1Amp DC28V DC B+ power supply
Programmable Digital
Input
Active when connected to B-
Case Dimensions
95mm x 86mm x 46.5mm
Panel Cutout
78mm x 66mm
CT Secondary Current
Rated: 5A
Working conditions
Temperature: (-25~+70)ºC Humidity: (20~93)%RH
Storage Condition
Temperature: (-25~+70)ºC
Protection Level
IP55: When waterproof rubber gasket installed between the
controller and panel fascia.
Insulation Intensity
Attach AC2.2kV voltage between AC high voltage terminal and low
voltage terminal (leak current below 3mA in 1 minute).
Weight
0.18kg
