7.4 SENSOR SELECTION
Table 10 Sensor Selection
No.
Items
Content
Remark
1
Temperature
Sensor
0 Not used
1 Low digital input is active
2 High digital input is active
3 User defined resistor type
4 VDO
5 SGH (Huanghe sensor)
6 SGD (Dongkang sensor)
7 CURTIS
8 DATCON
9 VOLVO-EC
10 SGX 120 DEGREE
Digital input is digital signal; low or high
electrical level can be selected to be
active, connecting to earth point will
mean that low electrical level is
selected, hang in air means high
electrical level is selected; cannot be
connected to power supply positive.
The range of user-defined resistor type
sensor is 0-6000Ω, by default SGD
sensor is selected.
2
Oil Pressure
Sensor
0 Not used
1 Low digital input is active
2 High digital input is active
3 User defined resistor type
4 VDO 10Bar
5 SGH (Huanghe sensor)
6 SGD (Dongkang sensor)
7 CURTIS
8 DATCON 10Bar
9 VOLVO-EC
10 SGX 10Bar
Digital input is digital signal; low or high
electrical level can be selected to be
active, connecting to earth point will
mean that low electrical level is
selected, hang in air means high
electrical level is selected; cannot be
connected to power supply positive.
The range of user-defined resistor type
sensor is 0-6000Ω, by default SGD
sensor is selected.
3
Fuel Level
Sensor
0 Not used
1 Low digital input is active
2 High digital input is active
3 User defined resistor type
4 SGH (Huanghe sensor)
5 SGD (Dongkang sensor)
6 Reserved 1
7 Reserved 2
Digital input is digital signal l; low or
high electrical level can be selected to
be active, connecting to earth point will
mean that low electrical level is
selected, hang in air means high
electrical level is selected; cannot be
connected to power supply positive.
The range of user-defined resistor type
sensor is 0-6000Ω, by default “Not
used” is selected
Before selecting fuel level sensor type,
digital input type must be set as 8.
