HGM6100LT Series Genset Controller User Manual Page 16 of 50
No.
Items
Description
than maintenance time of user setting or the maintenance type is date,
the current date is over the set value, and maintenance action is set as
shutdown, controller send shutdown alarm signal and it will be displayed
in LCD. Maintenance alarm can be reset by setting maintenance
parameters with password.
19
Input Shutdown
When external input is active, controller will send shutdown alarm signal
and it will be displayed in LCD.
20
Over Power
If over power detection is enabled, when the controller detects that the
over power value (power is positive) has exceeded the pre-set value and
the action selects “Shutdown”, it will initiate a shutdown alarm.
21
ECU Shutdown
If an error message is received from ECU via J1939, it will initiate a
shutdown alarm.
22
ECU Comm. Failure
If the module does not detect the ECU data, it will initiate a shutdown
alarm.
23
Short-circuit Shutdown
When short-circuit signal is enabled, and the short-circuit action selects
“Shutdown Alarm”, controller will initiate a shutdown alarm signal after
meeting the short-circuit requirements.
24
User Configured 1
Shutdown
When controller detects that the input port 1 selects 33 “User
Configured”, close/open is active and the action selects “Shutdown
Alarm”, when the controller meets the selection of active range （not
inactive）, the controller will initiate a shutdown alarm signal, and the
LCD will display the “User Configured 1 Shutdown”.
25
User Configured 2
Shutdown
When controller detects that the input port 2 selects 33 “User
Configured”, close/open is active and the action selects “Shutdown
Alarm”, when the controller meets the selection of active range （not
inactive）, the controller will initiate a shutdown alarm signal, and the
LCD will display the “User Configured 2 Shutdown”.
26
User Configured 3
Shutdown
When controller detects that the input port 3 selects 33 “User
Configured”, close/open is active and the action selects “Shutdown
Alarm”, when the controller meets the selection of active range （not
inactive）, the controller will initiate a shutdown alarm signal, and the
LCD will display the “User Configured 3 Shutdown”.
27
User Configured 4
Shutdown
When controller detects that the input port 4 selects 33 “User
Configured”, close/open is active and the action selects “Shutdown
Alarm”, when the controller meets the selection of active range （not
