HGM6100LT Series Genset Controller User Manual Page 47 of 50
13.14 PERKINS
It is suitable for ADEM3/ADEM4 engine control mode. Engine type is 2306, 2506, 1106, and 2806.
Table 33 – Connector
Terminals of controller
Connector
Remark
Programmable output 1
1, 10, 15, 33, 34
Set programmable output 1 as “Fuel
Output”.
Starting relay output
-
Connect to starter coil directly.
CAN_SCR
-
CAN communication shielding line.
CAN(H)
31
Using impedance 120Ω connecting line.
CAN(L)
32
Using impedance 120Ω connecting line.
Engine type: Perkins.
13.15 SCANIA
It is suitable for S6 engine control mode. Engine type is DC9, DC12, and DC16.
Table 34 – B1 Connector
Terminals of controller
B1 connector
Remark
Programmable output 1
3
Set programmable output 1 as “Fuel
Output”.
Starting relay output
-
Connect to starter coil directly.
CAN_SCR
-
CAN communication shielding line.
CAN(H)
9
Using impedance 120Ω connecting line.
CAN(L)
10
Using impedance 120Ω connecting line.
Engine type: Scania.
13.16 VOLVO EDC3
Suitable engine control model is TAD1240, TAD1241, and TAD1242.
Table 35 – “Stand alone” Connector
Terminals of controller
“Stand alone” connector
Remark
Programmable output 1
H
Set programmable output 1 as “Fuel
Output”.
Starting relay output
E
Programmable output 2
P
ECU power;
Set programmable output 2 as "ECU
power".
