Smartgen HGM6100LT SERIES User Manual

HGM6100LT Series Genset Controller User Manual Page 43 of 50
13.5 CUMMINS GCS-MODBUS
It is suitable for GCS engine control module. Use RS485-MODBUS to read information of engine. Engine
types are QSX15, QST30, QSK23/45/60/78 and so on.
Table 21 – D-SUB Connector 6
Terminals of controller
D-SUB connector 06
Remark
Programmable output 1
5&8
Set programmable output 1 as “Fuel
Output”. Outside expand relay, when fuel
output, connect port 06 and 08 of the
connector.
Starting relay output
-
Connect to starter coil directly.
Table 22 – D-SUB Connector 06
Terminals of controller
D-SUB connector 06
Remark
RS485 GND
20
CAN communication shielding line
(connect to ECU terminal only).
RS485+
21
Using impedance 120Ω connecting line.
RS485-
18
Using impedance 120Ω connecting line.
Engine type: Cummins QSK-MODBUS, Cummins QST-MODBUS, Cummins QSX-MODBUS.
13.6 CUMMINS QSM11
Table 23 – Engine OEM Connector
Terminals of controller
OEM connector of engine
Remark
Programmable output 1
38
Set programmable output 1 as “Fuel
Output”.
Starting relay output
-
Connect with starter coil directly.
CAN_SCR
-
CAN communication shielding line.
CAN(H)
46
Using impedance 120Ω connecting line.
CAN(L)
37
Using impedance 120Ω connecting line.
Engine type: common J1939.
