HGM6100LT Series Genset Controller User Manual Page 5 of 50
1 OVERVIEW
HGM6100LT series automatic controller is specially designed for applying to extremely high/low
temperature (-40ºC~+70ºC) environment. It is an automatic control and monitoring system for genset,
which integrates digital, intelligent and network techniques. It can reliably work in extreme temperature
environment due to its heated LCD and special electronic components. Moreover, it carries out
functions of automatic start/stop, data measurement, alarm protection and “three remote” (remote
control, remote measuring and remote communication). The controller uses LCD display, optional
display interface including Chinese, English, Spanish, Russian, Portuguese, Turkish, Polish and French
with easy and reliable operation.
HGM6100LT series automatic controller uses micro-processing technique which can achieve
precision measurement, value adjustment, timing and threshold setting etc. All the parameters can be
configured from front panel or use USB interface (or RS485 interface and ENTHERNET) to adjust via PC.
It can be widely used in all types of automatic control system for its compact structure, simple
connections and high reliability.
2 PERFORMANCE AND CHARACTERISTICS
HGM6100LT controller has two types:
HGM6110LT: It is used for single unit automation, controlling generator to start/stop by remote
start signal;
HGM6120LT: Based on HGM6110LT, it adds mains electric quantity monitoring and
mains/generator automatic switching control (AMF), especially suitable for the automation system
composed by mains and genset.
Main characteristics are as below,
132*64 LCD display with backlight, heated LCD in low temperature, and optional language
interface (Chinese, English, Spanish, Russian, Portuguese, Turkish, Polish and French), push-button
operation;
Acrylic screen, improved wearable and scratch resistance property. Front panel includes silica-gel
panel and keys;
Widely working temperature (-40ºC~+70ºC) enables the module working in a place of harsh
environmental conditions;
With RS485 communication port, can achieve “three remote” functions via MODBUS protocol;
ETHERNET communication port works together with cloud monitoring platform and mobile phone
APP can realize monitor function for genset at any time in any place;
With CANBUS port which can be connected to electronic injection with J1939, it not only can
monitor frequently-used data (such as water temperature, oil pressure, speed and fuel
consumption, etc.) but also can control start, stop, high speed and low speed (controller with
CANBUS port is needed) via CANBUS port.
Adapt to 3P4W, 3P3W, 1P2W and 2P3W (120V/240V), 50Hz/60Hz power system;
Can measure and display 3 phase voltage, 3 phase current, frequency, power parameter of
