HGM6100LT Series Genset Controller User Manual Page 34 of 50
8 PARAMETER SETTING
After controller is powered on, press to enter into the parameters setting menu:
1. Set Parameters
2. Information
3. Set Language
4. Event Log
5. ECU DM2
6. Maintenance
— Parameters Setting
All items in table7 can be set after inputting password “0318”. When the default password has
been changed, it needs to input the same password with controller for parameter setting via PC
software. If more parameter items need to be set or password is forgotten, such as voltage and current
calibration, please contact with the factory.
NOTE:
1) HGM6110LT, there are no items 1-5 in table7; programmable output 1-4 have no digital outputs about mains.
2) Please modify the internal parameters in standby mode (crank conditions, auxiliary input and output configuration,
multi delays, etc.) otherwise shutdown alarm or other abnormal conditions may appear.
3) The over-voltage threshold must be greater than the under-voltage threshold; otherwise over-voltage and
under-voltage will occur at the same time.
4) The over-speed threshold must be greater than under-speed threshold, otherwise over speed and under speed will
occur at the same time.
5) Set frequency value (after crank disconnect) as low as possible, in order to disconnect starter quickly.
6) Programmable input 1-5 cannot be set as the same items, otherwise it cannot realize correct function;
programmable output 1-4 can be set as the same item.
7) If need to shut down after cooling, please set any input as “stop after cooling “, then connect this input to ground;
or set high temperature stop action as “cooling stop”
— Information
1) LCD will display some information of controller, such as software version, issue date.
NOTE: Pressing will display the status of digital inputs and outputs.
2) Language
User may select display language as Chinese, English, Spanish, Russian, Portuguese, Turkish,
Polish and French.
3) LCD contrast
Press and (or and ) can adjust LCD contrast to make LCD characters clearer.
Adjustment range is 0-7.
