HGM6100LT Series Genset Controller User Manual Page 49 of 50
13.19 YUCHAI
It is suitable for Yuchai BOSCH common rail electronic-controlled engine.
Table 39 – Engine 42 Pins Port
Terminals of controller
Engine 42 pins port
Remark
Programmable output 1
1.40
Set programmable output 1 as “Fuel
Output”;
Connect to engine ignition lock.
Starting relay output
-
Connect to starter coil directly.
CAN_SCR
-
CAN communication shielding line.
CAN(H)
1.35
Using impedance 120Ω connecting line.
CAN(L)
1.34
Using impedance 120Ω connecting line.
Table 40 – Engine 2 Pins Port
Battery
Engine 2 pins port
Remark
Battery negative
1
Wire diameter 2.5mm
2
.
Battery positive
2
Wire diameter 2.5mm
2
.
Engine type: BOSCH.
13.20 WEICHAI
It is suitable for Weichai BOSCH common rail electronic-controlled engine.
Table 41 – Engine Port
Terminals of controller
Engine port
Remark
Programmable output 1
1.40
Set programmable output 1 as “Fuel
Output”;
Connect to engine ignition lock.
Starting relay output
1.61
CAN_SCR
-
CAN communication shielding line.
CAN(H)
1.35
Using impedance 120Ω connecting line.
CAN(L)
1.34
Using impedance 120Ω connecting line.
Engine type: GTSC1.
NOTE: If there is any question of connection between controller and ECU communication, please feel free to contact
SmartGen service.
