HGM6100LT Series Genset Controller User Manual Page 38 of 50
Fig.7 – Single Phase 2 Wire Connection Diagram
Fig.8 – 2 Phase 3 Wire Connection Diagram
NOTE: Recommend that the output of crank and fuel expand high capacity relay.
