6.3 TRIP AND STOP ALARM
When controller detects trip and stop alarms, it will immediately disconnect the generator closing
signals and engine will shut down after high-speed cooling.
Table 7 - Trip and Stop Alarms
No.
Type
Description
1
Over Current
When controller detects the current value of genset is higher than the
set value and action select “Trip and Stop”, it will send trip and stop
signals.
2
Maintenance Time
Due
When maintenance time countdown equals to 0, and action select
“Trip and Stop”, it will send trip stop signals.
3
Reverse Power
When controller detects that the reverse power value (power is
negative) of genset exceeds the pre-set value, and action type select
“Trip and Stop”, it will send trip and stop signals.
4
Over Power
When controller detects that the power value (power is positive) of
genset exceeds the pre-set value, and action type select “Trip and
Stop”, it will send trip and stop signals.
5
Input Trip and Stop
When input port configured as “Trip and Stop”, and it is active,
controller will send trip and stop signals.
6.4 TRIP ALARM
When controller detects trip alarms, it will immediately disconnects the generator closing signals and
genset does not shut down.
Table 8 - Trip Alarms
No.
Type
Description
1
Over Current
When controller detects the current value of genset is higher than the set
value and action select “Trip”, it will send trip signals.
2
Reverse Power
When controller detects that the reverse power value (power is negative)
of genset exceeds the pre-set value, and action type select “Trip”, it will
send trip signals.
3
Over Power
When controller detects that the power value (power is positive) of genset
exceeds the pre-set value, and action type select “Trip”, it will send trip
signals.
4
Input Trip
When input port configured as “Trip”, and it is active, controller will send
trip signals.
