HGM7100N GENSET CONTROLLER USER MANUAL
HGM7100N Genset Controller 2020-09-10 Version1.2 Page 22 of 47
No.
Items
Range
Default
Description
8
Warming Up Time
(0-3600)s
10
Warming time before close after genset
entering high speed running.
9
Cooling Time
(0-3600)s
10
Radiating time before gen-set stop, after it
unloads.
10
Stop Idle Time
(0-3600)s
0
Idle running time while gen-set stops.
11
ETS Solenoid Hold
(0-3600)s
20
Stop electromagnet’s power on time when
gen-set is closing down.
12
Wait For Stop Time
(0-3600)s
0
When “ETS Solenoid Hold” is set as 0, it is
the time between gen-set idle delay expired
and stopped completely;
When “ETS Solenoid Hold” is not 0, it is time
between ETS hold delay expired and
stopped.
13
After Stop Time
(0-3600)s
0
Time from gen-set stopped to standby.
Engine
1
Engine Type
(0-39)
0
Default: conventional engine.
2
Flywheel Teeth
(1.0-300.0)
118
It is tooth number of the engine, which is used
for judging starter crank disconnect
conditions and inspecting engine speed. For
details, please see the following installation
description.
3
Engine Rated
Speed
(0-6000)RPM
1500
Provide standards for judging over/under
speed and on-load speed.
4
Speed On-load
(0-100)%
90
The set value is rated speed percentage. The
controller detects it while gen-set preparing to
take the load, if the speed is less than the
on-load speed, gen-set will not enter the
normal operation period.
5
Speed Signal Loss
Delay
(0-3600)s
5
Time from the speed is detected as 0 to the
action confirmed.
6
Speed Signal Loss
Action
(0-1)
0
0: Warning; 1: Shutdown
7
Over Speed
Shutdown
(0-200)%
114
The setting value is the percentage of rated
speed, and delay value can be set.
8
Under Speed
Shutdown
(0-200)%
80
9
Over Speed
Warning
(0-200)%
110
The set value is the percentage of rated
speed, return value and delay value can be
set.
10
Under Speed
Warning
(0-200)%
86
11
Battery Rated
Voltage
(0-60.0)V
24.0
Provide standard for judging battery
over/under voltage.
12
Battery High
Voltage Warning
(0-200)%
120
The set value is the percentage of rated
voltage, return value and delay value can be
set.
13
Battery Low Voltage
Warning
(0-200)%
85
