HGM7100N GENSET CONTROLLER USER MANUAL
HGM7100N Genset Controller 2020-09-10 Version1.2 Page 23 of 47
No.
Items
Range
Default
Description
14
Charge Alt Fail
(0-60.0)V
8.0
If the voltage of charger D+(WL) is lower than
the set value during gen-set normal running,
controller will initiate fail to charge warning
alarms.
15
Start Attempts
(1-10)times
3
Maximum crank times when engine starts fail.
If reach this number, controller will send start
failure signals.
16
Crank Disconnect
Condition
(0-6)
2
For details please see table 14
There are 3 cranking disconnect conditions,
which can be used separately or together,
aiming to disconnect starter motor with
engine as soon as possible.
17
Frequency of Crank
Disconnect
(0-200)%
24
The set value is the percentage of Gen rated
frequency, when generator frequency is
higher than the set value, starter will be
disconnected. For Details please see the
following installation description.
18
Speed of Crank
Disconnect
(0-200)%
24
The set value is the percentage of the rated
speed, when speed is higher than the set
value, starter will disconnect. For details see
the following installation description.
19
Oil Pressure of
Crank Disconnect
(0-1000)kPa
200
When engine oil pressure is higher than the
set value, starter will disconnect. For details
see the following installation description.
20
Battery Low Voltage
Start Enabled
(0-1)
0
0: Disabled; 1:Enabled
21
Battery Low Voltage
Start Value
(1.0-60.0)V
10.0
It is the low-battery-start value. Active at auto
mode.
22
Battery Low Voltage
Stop Value
(1.0-60.0)V
24.0
The shutdown value after low-battery-start
and charged. Active at auto mode.
23
Battery Low Voltage
Start/Stop Delay
(0-3600)s
60
When battery voltage reached to engine start
threshold, engine will start up after delay
expired; when battery voltage reached to
engine stop threshold, engine will stop after
delay expired.
Generator
1
Power Supply
System
(0-3)
0
0: 3P4W;
1: 3P3W
2: 2P3W
3: 1P2W
2
Engine Poles
(2-64)
4
It is the number of engine poles, which can be
used for engine speed calculation when
speed sensor is not installed.
3
Rated Voltage
(30-30000)V
230
Provide standards for judging Gen over/under
voltage and loading voltage; if PT is used, this
value is primary voltage of PT.
