Page #24 background imageLoading...
Page #24 background image
HGM7100N GENSET CONTROLLER USER MANUAL
HGM7100N Genset Controller 2020-09-10 Version1.2 Page 24 of 47
No.
Items
Range
Default
Description
4
Voltage On-load
(0-200)%
85
The set value is rated voltage percentage.
Controller detects at preparing to take load,
when Gen voltage is less than load voltage, it
won't enter normal running period.
5
Rated Frequency
(10.0-600.0) Hz
50.0
Provide standards for judging over/under
frequency and on-load frequency.
6
Frequency On-load
(0-200)%
85
The set value is Gen rated frequency
percentage. The controller detects it while
gen-set prepares to take the load, if
frequency is less than the on-load frequency,
gen-set will not enter normal operation
period.
7
Voltage
Transformer (PT)
(0-1)
0
0: Disabled; 1: Enabled
8
Gen. Over Voltage
Shutdown
(0-200)%
120
The set values are rated voltage percentage
of generator, and delay value can be set.
9
Gen. Under Voltage
Shutdown
(0-200)%
80
10
Gen. Over
Frequency
Shutdown
(0-200)%
114
The set values are rated frequency
percentage of generator, and delay value can
be set.
11
Gen. Under
Frequency
Shutdown
(0-200)%
80
12
Gen. Over Voltage
Warning
(0-200)%
110
The set values are rated voltage percentage
of generator, and return value and delay
value can be set.
13
Gen. Under Voltage
Warning
(0-200)%
84
14
Gen. Over
Frequency Warning
(0-200)%
110
The set values are rated frequency
percentage of generator, and return value and
delay value can be set.
15
Gen. Under
Frequency Warning
(0-200)%
84
16
Gen. Loss of Phase
Check
(0-1)
1
0: Disabled; 1:Enabled
17
Gen. Reverse
Phase Check
(0-1)
1
Load
1
Current
Transformer Ratio
(5-6000)/5
500
It is the ratio of externally connected current
transformer.
2
Rated Current
(5-6000)A
500
It is the rated current of generator, which is
used as the standard for load current.
3
Rated Power
(0-6000)kW
276
It is the rated power of generator, which is
used as the standard for load current.
4
Over Current
Enable
(0-200)%
120
The set value is the percentage of rated
full-load current, and delay value can be set
as DMT or IDMT.
5
Over Power Setting
(0-1)
0
0: Disabled; 1: Enabled
