HGM7100N GENSET CONTROLLER USER MANUAL
HGM7100N Genset Controller 2020-09-10 Version1.2 Page 25 of 47
No.
Items
Range
Default
Description
6
Reverse Power
Setting
(0-1)
0
0: Disabled; 1: Enabled
Switch
1
Switching Time
(0-7200)s
5
Time from open mains to close generator or
from open generator to close mains.
2
Close Delay
(0-20.0)s
5.0
Pulse width of mains closed and generator
closed; 0s stands for constant output.
3
Open Delay
(0-20.0)s
3.0
Pulse width of open mains and open
generator.
4
Switching Detection
Time
(0-20.0)s
5.0
It is the time to detect auxiliary contactor after
ATS switching.
5
Switch Failure
Warning Enabled
(0-1)
0
0: Disabled; 1: Enabled
6
Open Detection
Enabled
(0-1)
0
7
Immediately Trip
when Mains
Dropout
(0-1)
1
0: Disabled; 1: Enabled
Module
1
Power On Mode
(0-2)
0
0: Stop Mode; 1: Manual Mode; 2: Auto Mode
2
Communication
Address
(1-254)
1
Controller address while in remote monitoring
status.
3
Communication
Stop-bit Setting
(0-1)
1
0: 2-bit stop bit; 1: 1-bit stop bit
4
Language Selection
(0-2)
0
0: Simplified Chinese; 1: English; 2: Other
5
Password Setting
(0-65535)
00318
This password used to enter into advanced
parameter setting.
6
Backlight Time
(0-3600) s
300
When it is 0s, LCD always light.
Schedule & Maintenance
1
Scheduled Start
Setting
(0-1)
0
0: Disabled; 1: Enabled
2
Scheduled Not Run
Setting
(0-1)
0
0: Disabled; 1: Enabled
3
Maintenance
Setting
(0-1)
0
0: Disabled; 1: Enabled
Analog Sensors
Temperature Sensor
1
Curve Type
(0-15)
7
SGX. For details see Table 13
2
Open Circuit Action
(0-2)
0
0: Warning; 1: Shutdown; 2: None
3
High Temp
Shutdown Setting
(0-300)ºC
98
When temperature value of externally
connected temperature sensor is higher than
the set point, controller will initiate high
temperature shutdown alarm (judgment only
starts after safety on delay expired). Delay
value can be set.
