Smartgen HGM7100N Series User Manual

HGM7100N GENSET CONTROLLER USER MANUAL
HGM7100N Genset Controller 2020-09-10 Version1.2 Page 26 of 47
No.
Items
Range
Default
Description
4
High Temp Warning
Setting
(0-300)ºC
95
When temperature value of externally
connected temperature sensor is higher than
the setting point, controller will initiate high
temperature warning alarm (judgment only
starts after safety on delay expired). Return
value and delay value can be set.
5
Low Temp Warning
Setting
(0-1)
0
0: Disabled; 1: Enabled
Oil Pressure Sensor
1
Curve Type
(0-15)
7
SGX. For details see table 13.
2
Open Circuit Action
(0-2)
0
0: Warning; 1: Shutdown; 2: None
3
Low Oil Pressure
Shutdown Setting
(0-1000)kPa
103
When pressure value of externally connected
oil pressure sensor is lower than the setting
point, controller will initiate low oil pressure
shutdown alarm (judgment only starts after
safety on delay expired). Delay value can be
set.
4
Low Oil Pressure
Warning Setting
(0-1000)kPa
124
When pressure value of externally connected
oil pressure sensor is lower than the setting
point, controller will initiate low oil pressure
warning alarm (judgment only starts after
safety on delay expired). Return value and
delay value can be set.
5
Sensor Type
(0-2)
0
0: Resistor type; 1: Current type; 2: Voltage
type.
Level Sensor
1
Curve Type
(0-15)
4
SGH. For details see table 13.
2
Open Circuit Action
(0-2)
0
0: Warning; 1: Shutdown; 2: None
3
Low Level Warning
(0-300)%
10
When the value of external connected fuel
level sensor is lower than the setting point,
controller will initiate low liquid level warning
alarm (always judge). Return value and delay
value can be set.
4
Low Level
Shutdown
(0-300)%
8
When the value of external connected level
sensor is lower than the setting point,
controller will initiate low liquid level shutdown
alarm (always judge). Delay value can be set.
Flexible Sensor 1
1
Flexible Sensor 1
Setting
(0-3)
0
0: Not Used; 1:Temperature Sensor;
2:Pressure Sensor; 3:Fuel Level Sensor
2
Sensor Type
(0-2)
0
0: Resistor type; 1: Current type; 2: Voltage
type.
Flexible Sensor 2
1
Flexible Sensor 2
Setting
(0-3)
0
0: Not Used; 1:Temperature Sensor;
2:Pressure Sensor; 3:Fuel Level Sensor
Digital Inputs
Digital Input 1
