Smartgen HGM7100N Series User Manual

HGM7100N GENSET CONTROLLER USER MANUAL
HGM7100N Genset Controller 2020-09-10 Version1.2 Page 27 of 47
No.
Items
Range
Default
Description
1
Content Setting
(0-50)
28
Remote start (on-load). Details to see table
12
2
Active Type
(0-1)
0
0: Close; 1: Open
Digital Input 2
1
Content Setting
(0-50)
26
High temperature shutdown input. Details to
see table 12
2
Active Type
(0-1)
0
0: Close; 1: Open
Digital Input 3
1
Content Setting
(0-50)
27
Low oil pressure shutdown input. Details to
see table 12
2
Active Type
(0-1)
0
0: Close; 1: Open
Digital Input 4
1
Content Setting
(0-50)
0
User defined. Details to see table 12
2
Active Type
(0-1)
0
0: Close; 1: Open
3
Active Range
(0-3)
2
0: From safety on delay; 1: From crank; 2:
Always; 3:Never
4
Active Action
(0-4)
0
0: Warning; 1: Shutdown; 2: Trip and Stop; 3:
Trip; 4: Indication.
5
Active Delay
(0-20.0)s
2.0
Time from detecting input port is active to
confirmation.
6
Description
LCD displays corresponding content when
input port is active.
Digital Input 5
1
Content Setting
(0-50)
0
User defined. Details to see table 12.
2
Active Type
(0-1)
0
0: Close; 1: Open
3
Active Range
(0-3)
2
0: From safety on delay; 1: From crank; 2:
Always; 3:Never
4
Active Action
(0-4)
1
0: Warning; 1: Shutdown; 2: Trip and Stop; 3:
Trip; 4: Indication.
5
Active Delay
(0-20.0)s
2.0
Time from detecting input port is active to
confirmation.
6
Description
LCD displays corresponding content when
input port is active.
Digital Input 6
1
Content Setting
(0-50)
0
User defined. Details to see table 12.
2
Active Type
(0-1)
0
0: Close; 1: Open
3
Active Range
(0-3)
2
0: From safety on delay; 1: From crank; 2:
Always; 3:Never
4
Active Action
(0-4)
2
0: Warning; 1: Shutdown; 2: Trip and Stop; 3:
Trip; 4: Indication.
5
Active Delay
(0-20.0)s
2.0
Time from detecting input port is active to
confirmation.
6
Description
LCD displays corresponding content when
input port is active.
Digital Input 7
1
Content Setting
(0-50)
0
User defined. Details to see table 12.
2
Active Type
(0-1)
0
0: Close; 1: Open
