Smartgen HGM7220N Series User Manual

HGM7220N/HGM7220S GENSET CONTROLLER USER MANUAL
HGM7220N/HGM7220S Genset Controller 2019-02-28 Version 1.0 Page 30 of 60
No.
Items
Range
Default
Description
4
High Temp
Warning
(-50-300)ºC
95
When externally connected temperature
sensor value is higher than the set point,
controller will initiate high temperature
warning alarm. It is only judged after “safety
on delay” is over. Return value and delay
value can be set.
5
Low Temp Warning
(0-1)
0
0: Disabled; 1: Enabled
Oil Pressure Sensor
1
Curve Type
(0-15)
7
SGX. For details please see table 13.
2
Open Circuit Action
(0-2)
0
0: Warning; 1: Shutdown; 2: None
3
Low Oil Pressure
Shutdown
(0-1000)kPa
103
When externally connected oil pressure
sensor value is lower than the set point,
controller will initiate low oil pressure
shutdown alarm. It is only judged after
“safety on delay” is over. Delay value can be
set.
4
Low Oil Pressure
Warning
(0-1000)kPa
124
When externally connected oil pressure
sensor value is lower than the set point,
controller will initiate low oil pressure
warning alarm. It is only judged after “safety
on delay” is over. Return value and delay
value can be set.
5
Sensor Type
(0-2)
0
0: Resistor type; 1: Current type; 2: Voltage
type.
Level Sensor
1
Curve Type
(0-15)
4
SGH. For details please see table 13.
2
Open Circuit Action
(0-2)
0
0: Warning; 1: Shutdown; 2: None
3
Low Level Warning
(0-300)%
10
When the value of externally connected fuel
level sensor is lower than the set point,
controller will initiate low liquid level warning
alarm. It is always judged. Return value and
delay value can be set.
4
Low Level
Shutdown
(0-300)%
8
When the value of external connected level
sensor is lower than the set point, controller
will initiate low liquid level shutdown alarm. It
is always judged. Delay value can be set.
Flexible Sensor 1
1
Flexible Sensor 1
(0-3)
0
0: Not Used; 1:Temperature Sensor;
2:Pressure Sensor; 3:Fuel Level Sensor
2
Sensor Type
(0-2)
0
0: Resistor type; 1: Current type; 2: Voltage
type.
Flexible Sensor 2
1
Flexible Sensor 2
(0-3)
0
0: Not Used; 1:Temperature Sensor;
2:Pressure Sensor; 3:Fuel Level Sensor
Digital Inputs
Digital Input 1
1
Content Setting
(0-50)
28
Remote start (on-load). For details please
see table 12.
