Smartgen HGM7220N Series

HGM7220N/HGM7220S GENSET CONTROLLER USER MANUAL
HGM7220N/HGM7220S Genset Controller 2019-02-28 Version 1.0 Page 29 of 60
No.
Items
Range
Default
Description
15
Fail Sync Delay
(0-3600)s
120
The max. waiting sync. time;
if time is due and still meets
the sync. conditions, then
sync. failure alarm is issued.
16
Sync. Detection
Time
(0.1-1.0) s
0.6
During sync. changeover,
sync. close or open output
delay starts, during the delay
if correct close/open status is
detected, then close/open
pulse output is stopped; if
when the delay is over, the
correct close/open status is
not detected, then transfer
failure trip alarm shall be
issued.
NOTE: if detection time is less
than breaker C/O time, then
detection time is C/O time.
Module Setting
1
Power On Mode
(0-2)
0
0: Stop Mode; 1: Manual Mode; 2: Auto
Mode
2
Slave ID
(1-254)
1
Controller address in remote monitoring
status.
3
Communication
Stop-bit Setting
(0-1)
1
0: 2-bit stop bit; 1: 1-bit stop bit
4
Language
(0-2)
0
0: Simplified Chinese; 1: English; 2: Other
5
Password
(0-65535)
00318
This password is used to enter advanced
parameter setting.
6
LCD Light Time
(0-3600)s
300
When it is 0s, LCD always is light.
Schedule & Maintenance Setting
1
Scheduler Run
(0-1)
0
0: Disabled; 1: Enabled
2
Scheduler Not Run
(0-1)
0
0: Disabled; 1: Enabled
3
Maintenance
(0-1)
0
0: Disabled; 1: Enabled
Analog Sensor Setting
Temperature Sensor
1
Curve Type
(0-15)
7
SGX. For details please see Table 13.
2
Open Circuit Action
(0-2)
0
0: Warning; 1: Shutdown; 2: None
3
High Temp
Shutdown
(-50-300)ºC
98
When externally connected temperature
sensor value is higher than the set point,
controller will initiate high temperature
shutdown alarm. It is only judged after
“safety on delay” is over. Delay value can be
set.
