HGM7220N/HGM7220S GENSET CONTROLLER USER MANUAL
HGM7220N/HGM7220S Genset Controller 2019-02-28 Version 1.0 Page 35 of 60
No.
Type
Description
49
Common Ele Trip
Activated when common electrical trip and stop occurs.
50
Common Shutdown
Activated when common shutdown occurs.
51
Common Trip Alarm
Activated when common trip alarms occur.
52
Common Warn Alarm
Activated when common warnings occur.
53
Reserved
54
Battery High Voltage
Activated when battery voltage is over too high.
55
Battery Low Voltage
Activated when battery voltage is over too low.
56
Charge Alt Fail
Activated when generator “fail to charge” alarms occur.
57
Reserved
HGM7220N: Reserved.
Sync Indication
HGM7220S: Output when sync. conditions are satisfied.
58
Reserved
59
Reserved
60
ECU Warn Alarm
It is indicated that ECU sends a warning alarm signal.
61
ECU Shutdown Alarm
It is indicated that ECU sends a shutdown alarm signal.
62
ECU Com. Fail
In case ECU is selected for engine type, it is activated when
speed signal is not received from “start idle” to “stop idle”.
63
Reserved
64
Reserved
65
Reserved
66
Reserved
67
Reserved
68
Reserved
69
Digital Input 1 Active
Activated when input port 1 is active.
70
Digital Input 2 Active
Activated when input port 2 is active.
71
Digital Input 3 Active
Activated when input port 3 is active.
72
Digital Input 4 Active
Activated when input port 4 is active.
73
Digital Input 5 Active
Activated when input port 5 is active.
74
Digital Input 6 Active
Activated when input port 6 is active.
75
Digital Input 7 Active
Activated when input port 7 is active.
76-
98
Reserved
99
Emergency Stop Alarm
Activated when emergency stop alarm occurs.
100
Failed to Start Alarm
Activated when “fail to start” alarm occurs.
101
Failed to Stop Alarm
Activated when “fail to stop” warning occurs.
102
Under Speed Warning
Activated when engine under speed warning occurs.
103
Under Speed Shutdown
Activated when engine under speed shutdown occurs.
104
Over Speed Warning
Activated when engine over speed warning alarm occurs.
105
Over Speed Shutdown
Activated when over speed shutdown alarms occur.
106
Reserved
107
Reserved
108
Reserved
109
Gen. Over Freq Warning
Activated when generator over frequency warning alarm
occurs.
