Smartgen HGM7220N Series

HGM7220N/HGM7220S GENSET CONTROLLER USER MANUAL
HGM7220N/HGM7220S Genset Controller 2019-02-28 Version 1.0 Page 36 of 60
No.
Type
Description
110
Gen. Over Freq Shutdown
Activated when generator over frequency shutdown alarm
occurs.
111
Gen. Over Voltage Warning
Activated when generator over voltage warning alarm occurs.
112
Gen. Over Volt Shutdown
Activated when generator over voltage shutdown alarm
occurs.
113
Gen. Under Frequency Warning
Activated when generator under frequency warning alarm
occurs.
114
Gen. Under Frequency
Shutdown
Activated when generator under frequency shutdown alarm
occurs.
115
Gen. Under Voltage Warning
Activated when generator under voltage warning alarm
occurs.
116
Gen. Under Voltage Shutdown
Activated when generator under voltage shutdown alarm
occurs.
117
Gen. Loss of Phase
Activated when generator loss of phase alarm occurs.
118
Gen. Reverse Phase
Activated when generator phase sequence wrong alarm
occurs.
119
Reserved
120
Over Power Alarm
121
Reserved
122
Reverse Power
Activated when controller detects that generator power is
reversed.
123
Over Current Alarm
Activated when over current occurs.
124
Reserved
125
Mains Inactive
126
Mains Over Frequency
127
Mains Over Voltage
128
Mains Under Frequency
129
Mains Under Voltage
130
Mains Reverse Phase
131
Mains Loss Of Phase
132-
138
Reserved
139
High Temp Warning
Activated when high temperature warning alarms occurs.
140
Low Temp Warning
Activated when low temperature warning alarms occurs.
141
High Temp Shutdown Alarm
Activated when high temperature shutdown alarms occurs.
142
Reserved
143
Low Oil Pressure Warning
Activated when low oil pressure warning alarms occurs.
144
Low Oil Pressure Shutdown
Activated when low oil pressure shutdown alarms occurs.
145
Oil Pressure Sensor Open
Circuit
Activated when oil pressure open circuit alarms occurs.
146
Reserved
147
Low Level Warning
Activated when low fuel level alarms occurs.
148
Reserved
