Patrol Settings
You can select some preset positions for the Network Camera to patrol.
Please follow the steps below to set up a patrol schedule:
1. Click a preset location on the list and click Select.
2. The selected preset location will be displayed on the Source list.
3. Set the Dwelling time for the preset location during auto patrol. You can also manually enter
a value in the blank and click Update.
4. Repeat step 1 and 3 to select additional preset locations.
5. If you want to delete a selected location, select it from the Source list and click Remove.
6. Select a location and click Up or Down to rearrange the patrol order.
7. Adjust the Auto pan/patrol speed. 1(slow) ~5(fast)
8. Click Save to enable the settings.
right
left
up
down
right
left
10
10
10
1
2
6
5
8
3
7
