How to Order
５２－ＩＰ８００１－０ ＊ ４－ ＊ －＊－ ＊
ＩＰ８００１－０ ＊ ＊－ ＊ －＊－ ＊
＊1: If two or more accessories are required, the part
numbers should be made according to alphabetical
order.
＜Ex＞IP8001-010-EW
＊2: When “52-“ ATEX type specify symbol “M”, ”2”, ”5”,
blue cable grant is equipped for electric
connection.
Pressure gauge
1
0.2MPa
2
0.3MPa
3
1.0MPa
Type
001
Smart positioner
Lever Type
Construction
0
Standard type
2
Output function
{analog output (4-20mADC)+ alarm outputX2}
3
HART communication function (preparing)
Construction
4
Intrinsically safe explosion-protected
(ATEX)+output function
+HART communication function
For CE marking
NIL
-
Q
For CE marking
ATEX Temp. class
NIL
T4
T6
T5/T6
For ATEX (preparing)
52
ATEX Category1
Connection
Air
Electric
NIL
Rc1/4
G1/2
M
Rc1/4
M20×1.5
*2
N
Rc1/4
1/2NPT
1
1/4NPT
G1/2
2
1/4NPT
M20×1.5
*2
3
1/4NPT
1/2NPT
4
G1/4
G1/2
5
G1/4
M20×1.5
*2
6
G1/4
1/2NPT
Accessory
*1
NIL
No accessory
E
With feedback lever unit for stroke 35 to
100mm.
F
With feedback lever unit for stroke 50 to
140mm.
W
With body cover window.
