No.IP8S-OM00009
5
Introduction
IP8001 smart positioner is mounted on a pneumatic actuator to receive a 2-wire 4 to 20mADC
input current from an adjusting meter (controller), to operate a pneumatic pilot valve and to control
motion of the pneumatic actuator by electronic control feedback. Also, it has setting parameters
which can optionally change the relation between the input current and actuator opening. This
manual is intended to explain how to handle the IP8001 smart positioner.
Specifications
Table 1 Specifications
Item
Model
IP8001-0**
Input current
4～20mADC
*1
(2 wire system, separate power source unnecessary)
Minimum current
3.85mADC or more
Voltage between terminals
12VDC (Input resistance equivalent to 600Ω, at 20mADC)
Max supply power
1W
*2
(I
max
:100mADC, V
max
:28VDC)
Supply air pressure
0.14～0.7MPa
Standard stroke
10～85mm (Feedback lever allowable runout angle 10
o
to 30
o *3
)
Sensitivity
±0.2%F.S. or less
*4
Linearity
±1%F.S. or less
*4
1%F.S.以内
Hysteresis
0.5%F.S. or less
Repeatability
±0.5%F.S. or less
Temperature coefficient
0.05%F.S./
o
C or less
Max output flow rate
*5
80 L/min(ANR) or more (SUP=0.14MPa)
200 L/min(ANR) or more (SUP=0.4MPa)
Air consumption
*5
2 L/min(ANR) or less (SUP=0.14MPa)
4 L/min(ANR) or less (SUP=0.4MPa)
Ambient temperature and
operating fluid temperature
-20
o
C～80
o
C(Non Explosion,IS Explosion:T4/T5)
＊
6,
＊
7
-20℃～60℃(IS Explosion:T6)
Explosion protected
construction
(Option, preparing)
*8
ATEX Intrinsic safety type of explosion protected construction
0344 Ⅱ1G Ex iaⅡC T4/T5/T6 Ga
Intrinsically safe parameter
Ui≦28V、Ii≦100mA、Pi≦0.7W、Ci≦12.5nF、Li≦1.5mH
Classification of degree of
Protection
JISF8007 IP65 (Conform to IEC Pub.60529)
Communication
(Option, preparing)
HART communication
Air connection ports
Rc1/4, 1/4NPT, G1/4 female thread
Electrical connections
G1/2, M20×1.5, 1/2NPT female thread
Material
Body/Cover : Die cast aluminum
（Coating : Epoxy organization resin baked）
Shaft / Screw : Stainless
Weight
Approx 2.6kg
