3 Installation
-37-
No.PS※※-OMW0009-A
○Connector pin No. (Cable side)
Connector pin No.
Lead wire colour
Description
1
Brown
DC(+)
2
White
OUT2
3
Blue
DC(-)
4
Black
OUT1(C/Q)
ZS-31-B (Cable with connector)
ZS-31-C (Cable with connector)
