SMC Networks ISA3 Series User Manual

3 Installation
-38-
No.PS※※-OMW0009-A
ISA-21- (Centralized lead wire)
•For 2 to 3 stations
M12 Connector No.
Pin No.
Description
Lead wire colour
(Output wire colour)
1
1
DC(+)
Brown

Orange
2
OUT2
3
DC(-)
Blue

Black
4
OUT1
2
1
DC(+)
Brown

Red
2
OUT2
3
DC(-)
Blue

White
4
OUT1
3
1
DC(+)
Brown

Green
2
OUT2
3
DC(-)
Blue

Gray
4
OUT1
