SMC Networks ISA3 Series User Manual

3 Installation
-39-
No.PS※※-OMW0009-A
•For 4 to 6 stations
M12 Connector No.
Pin No.
Description
Lead wire colour
(Output wire colour)
1
1
DC(+)
Brown

Yellow
2
OUT2
3
DC(-)
Blue

Black
4
OUT1
2
1
DC(+)
Brown

Purple
2
OUT2
3
DC(-)
Blue

White
4
OUT1
3
1
DC(+)
Brown

Gray/Black
2
OUT2
3
DC(-)
Blue

Gray
4
OUT1
4
1
DC(+)
Brown

Orange/Black
2
OUT2
3
DC(-)
Blue

Orange
4
OUT1
5
1
DC(+)
Brown

Red/Black
2
OUT2
3
DC(-)
Blue

Red
4
OUT1
6
1
DC(+)
Brown

Green/Black
2
OUT2
3
DC(-)
Blue

Green
4
OUT1
: Brown and blue are connected in the product inside.
Caution
The electrical entry of centralized lead wire for M12 connector is on the right side.
If the supply port on the right side is used, arrange the centralized lead wire so that it does not interfere with
the control unit.
