4 How to use
-59-
No.PS※※-OMW0009-A
Delay time setting
Set the delay time referring to the setting method on
page 50.
When OUT port side pressure
is selected: [EdH2]
When SUP port side pressure
is selected: [SdH2]
When OUT port side pressure
is selected: [EdL2]
When SUP port side pressure
is selected: [SdL2]
Press the SET button to set.
Display colour setting
Press the UP or DOWN button to select the display colour.
Press the SET button to set. Return to function selection mode.
[F 2] Setting of OUT2 completed
1: Selected item becomes valid after pressing the SET button.
2: After enabling the setting by pressing the SET button, it is possible to return to the measurement mode by keeping pressing the
SET button for 2 seconds or longer.
Move on to display colour
setting.
To Next Page
