4 How to use
-68-
No.PS※※-OMW0009-A
•Level bar display
It is possible to visually display the current detection distance (clearance guideline) on the sub display.
: The level bar is not displayed for the pressure value on the SUP port side and OUT port side.
9 level display
The switch point value bar is only displayed in hysteresis mode.
In window comparator mode, error output and switch output off setting, the switch point value bar will not be
displayed. Only the level meter is displayed.
Boundary value of the switch point value bar and level bar
In hysteresis mode
Hysteresis mode varies depending on the switch point.
Relationship between boundary value and display value of the level bar/switch point value bar and process data
Distance type
Level 1
Level 2

Level 3
Level 4
Level 4
Display
value
ISA-F
Constantly
ON
60 or less
(60 to 36)
X+30
(35 to 31)
X+25
(30 to 26)
X+20
(25 to 21)
ISA3-G
300 or less
(300 to 176)
X+150
(175 to 151)
X+125
(150 to 126)
X+100
(125 to 101)
ISA3-H
500 or less
(500 to 351)
X+300
(350 to 301)
X+250
(300 to 251)
X+200
(250 to 201)
Process
data
ISA3-F
ISA3-G
3000 or less
(3000 to 1751)
X+1500
(1750 to 1501)
X+1250
(1500 to 1251)
X+1000
(1250 to 1001)
ISA3-H
2500 or less
(2500 to 1751)
Distance type
Level 6
Level 7
Level 8
Level 9
Weight
Display
value
ISA-F
X+15
(20 to 16)
X+10
(15 to 11)
X+5
(10 to 6)
X
(5 to 0)
5
ISA3-G
X+75
(100 to 76)
X+50
(75 to 51)
X+25
(50 to 26)
X
(25 to 0)
25
ISA3-H
X+150
(200 to 151)
X+100
(150 to 101)
X+50
(100 to 51)
X
(50 to 0)
50
Process
data
ISA3-F
ISA3-G
X+750
(1000 to 751)
X+500
(750 to 501)
X+250
(500 to 251)
X
(250 to 0)
250
ISA3-H
: The value in the brackets in level 2 shows the boundary value.
