SMC Networks ISA3 Series User Manual

4 How to use
-69-
No.PS※※-OMW0009-A
X: Switch point is divided by weight. If the switch point is divisible, the weight will be X.
Example) When the switch point of the display value = 50 with ISA3-G
This is divisible by weight, so X = 25.
When the switch point of the display value = 75 with ISA3-H
The weight is 50, so X = 25.
In window comparator mode, error output, switch output off
The boundary value is fixed.
Relationship between level bar, display value and process data
Distance type
Level 1
Level 2
Level 3
Level 4
Level 5
Display
value
ISA3-F
Constantly
ON
60 or less
Below 35
Below 30
Below 25
ISA3-G
300 or less
Below 175
Below 150
Below 125
ISA3-H
500 or less
Below 350
Below 300
Below 250
Process
data
ISA3-F
ISA3-G
3000 or less
Below 1750
Below 1500
Below 1250
ISA3-H
2500 or less
Distance type
Level 6
Level 7
Level 8
Level 9
Display
value
ISA3-F
Below 20
Below 15
Below 10
Below 5
ISA3-G
Below 100
Below 75
Below 50
Below 25
ISA3-H
Below 200
Below 150
Below 100
Below 50
Process
data
ISA3-F
ISA3-G
Below 1000
Below 750
Below 500
Below 250
ISA3-H
