-76-
No.PF※※-OMJ0006-G
Details of rated flow range, display flow rate range, set flow rate range and maximum analogue output according
to the gas mixture selected.
Model
Ratio
Rated flow range
Display flow range
Set flow range
Max. analogue output
Ar
CO
2
Voltage
V max.
Current
I max.
PFM710
92%
8%
0.2 to 7.0 L/min
0.2 to 7.4 L/min
0 to 7.4 L/min
3.80 V
15.2 mA
90%
10%
80%
20%
70%
30%
60%
40%
PFM725
92%
8%
0.5 to 25.0 L/min
0.5 to 26.3 L/min
0 to 26.3 L/min
5.00 V
20.0 mA
90%
10%
80%
20%
0.5 to 20.0 L/min
0.5 to 21.0 L/min
0 to 21.0 L/min
4.20 V
16.8 mA
70%
30%
60%
40%
PFM750
92%
8%
1.0 to 50.0 L/min
1.0 to 52.5 L/min
0 to 52.5 L/min
5.00 V
20.0 mA
90%
10%
80%
20%
1.0 to 40.0 L/min
1.0 to 42.0 L/min
0 to 42 L/min
4.20 V
16.8 mA
70%
30%
60%
40%
PFM711
92%
8%
2 to 100 L/min
2 to 105 L/min
0 to 105 L/min
5.00 V
20.0 mA
90%
10%
80%
20%
2 to 90 L/min
2 to 95 L/min
0 to 95 L/min
4.60 V
18.4 mA
70%
30%
2 to 80 L/min
2 to 84 L/min
0 to 84 L/min
4.20 V
16.8 mA
60%
40%
Other specifications are the same as the standard product.
Output characteristic when gas mixture is selected
