SMC Networks ZK2 Series User Manual

-30-
No. ZK2-OM00201
6. Construction/Replacement Parts
6.1. Construction for Single Unit
(Including single unit for manifold)
Pressure switch with
energy saving function
Pressure switch for vacuum
Pressure sensor
High-noise reduction silencer
6.2. Component Parts
No.
Item
Material
Remarks
1
Valve body assembly
Resin
HNBR, NBR and steel are also used
2
Needle assembly
Brass
Electroless nickel plated brass, resin, steel and NBR are used
3
Ejector body assembly
Resin
HNBR, NBR and steel are also used
4
Ejector assembly
Resin
NBR is also used
5
Filter case assembly
Resin
Case body: Polycarbonate (Refer to Note on page 46.)
