-51-
No. ZK2-OM00201
■Weight
Single Unit
Model of a single unit
Weight (g)
ZK2P00K□N□ (Vacuum pump, without pressure sensor and pressure switch)
83
ZK2A□K□N□ (Ejector, without pressure sensor and pressure switch)
81
ZK2A□N0NN (Ejector, without valve)
54
ZK2C□K□N□ (Ejector for manifold, without pressure sensor and pressure switch)
85
Pressure Sensor, Pressure switch for vacuum
Model of pressure sensor and pressure switch for vacuum
Weight (g)
ZK2-PS□-A (Weight excluding the cable)
5
ZK2-ZS□-A (Weight excluding the lead wire assembly with connector)
14
Manifold Base
Calculation of Weight for the Manifold Type
(Single unit weight x Number of stations)
+ (Pressure sensor/Pressure switch for vacuum weight x Number of stations)
+ Manifold base
Example: 5-station manifold with pressure sensor
85g x 5pcs. + 5g x 5pcs. + 141g = 591g
Stations
1
2
3
4
5
6
7
8
9
10
Weight (g)
129
132
135
138
141
144
147
149
152
155
