SMC Networks ZK2 Series User Manual

-47-
No. ZK2-OM00201
9. Specifications
■General Specifications
Ambient temperature range
-5 to 50
o
C (Without pressure sensor and pressure switch, With pressure switch)
0 to 50
o
C (With pressure sensor)
5 to 50
o
C (With pressure switch with energy saving function)
(No condensation)
Fluid
Air
Vibration resistance
Note 1)
30m/s
2
(Without pressure sensor and pressure switch, With pressure sensor)
20m/s
2
(With pressure switch)
Impact resistance
Note 2,3)
150m/s
2
(Without pressure sensor and pressure switch, With pressure sensor)
100m/s
2
(With pressure switch)
Standard
CE, RoHS
Note 1) The characteristics are satisfied when tested for 2 hours in each of the X, Y and Z directions at 10 to 500 Hz without
energization. (Initial value)
Note 2) The characteristics are satisfied when tested one time in each of the X, Y and Z directions without energization. (Initial
value)
Note 3) For valve type R (Self-holding release valve linked), impact resistance is 50m/s
2
.
■Valve Common Specifications
Valve model
Note 4)
ZK2-VA□K
ZK2-VA□R
ZK2-VA□J
Type of
Actuation
Note 5)
Supply valve: N.C.
Release valve: N.C.
Supply valve: Self-holding release
valve linked
Release valve: N.C.
Supply valve: N.C.
Release valve: None
Valve configuration
Pilot operated dual 2 port
Pilot operated 2 port
Operating pressure
range
0.3 to 0.6 MPa
Valve construction
Poppet seal
Manual override
Push type
Rated voltage
24 VDC, 12VDC
Power consumption
0.35W
Lead wire
(ZK2-LV-□□-A)
Conductor cross section: 0.2 mm
2
(AWG24)
Insulator O.D.: 1.4 mm
Note 4) Refer to Valve assembly on page 31 for the valve model number.
Note 5) ZK2-VA□R: When the supply valve is energized (20 ms or more), the supply valve keep ON position even after
energization is stopped. When release valve is energized, the supply valve is turned off in conjunction with the
operation of the release valve.
ZK2-VA□K: Supply valve turns off when is not energized. Select this type when pressure switch with energy saving
function is used.
■Noise Level (Reference values)
Model
ZK2□07
ZK2□10
ZK2□12
ZK2□15
Noise level
[dB(A)]
ZK2G (High-noise reduction silencer exhaust)
46
55
63
69
ZK2A (Silencer exhaust)
59
66
75
76
