POSITIONING:
4 INSTALLATION INSTRUCTIONS FOR THE AFTER-
SALES SERVICE
4.1 Plumbinghookup
Watersupplyanddrainhookup
Water supply and drain connection:
The water pipelines and electricity supply cable lead out of the bottom right-hand
corner of the appliance. Connect the water intake hose to a connector with ¾”
gas threaded fitting, fitting the filter A provided.
The connection to the water mains must only be made with new hoses; the use
of old or worn hoses is not permitted.
FOR MODELS WITH WATER SOFTENER:
An `approved` double check valve or some other no less effective device
providing backflow prevention protection to at least fluid category three
shall be fitted at the point of connection between the water supply and the
fitting or appliance.
FOR MODELS WITHOUT WATER SOFTENER:
An `approved` single check valve or some other no less effective device
providing backflow prevention protection to at least fluid category two
shall be fitted at the point of connection between the water supply and the
fitting or appliance.
The dynamic water supply pressure must be between 1 and 6 bar; if it is higher, installation of a
pressurereducerisnecessary.
Itisessentialtofitamainstoptaponthewaterintakedeliverpipeline;thetapmustbeaccessible
after installation of the appliance, so
do not install it behind the dishwasher. The stated cycle
duration applies to appliances supplied with hot water >50°C<60°C. If the dishwasher is supplied
withcoldwater,thecycledurationmightincreasedependingontheintakewatertemperature.The
dishwasherisfittedwithadrainpumpandcanoperatewith
drainconnectionsonthefloororwall.
Caution:theindoorsystemandpremisesinwhichequipmentforinstitutionsisinstalled
mustcomplywiththerelevantregulations.
Themanufacturerdeclinesallliabilityfordirectorindirectinjuryordamagederivingfromfailure
tocomplywiththeseregulations.
Before installation, check that there are no objects or materials in the vicinity which may be
damagedbysteamorsplashesofwashingsolution,orthatanysuchitemsaresuitablyprotected.
Placethedishwasherinthechosenpointandremovetheprotectivefilm.
Levelthedishwasher(withtheaidofaspiritlevel)onitsadjustablefeettoensurethatitisstable;
allothermountingsolutionsmustbeapprovedbythemanufacturer.
