Smeg CW521D - INSTRUCTIONS FOR THE USER; 8.1 Control panel


‐CW521/531

25
8 INSTRUCTIONS FOR THE USER
8.1 Controlpanel

 On‐offbutton

 Programselectionbutton

 StartCONFIRM/PAUSEbutton

 Totalemptyingbutton(tankandboiler)

 Additionalfunctionselectionbutton

 L1Mainspoweronlight

 L2Intake/standbycycleinprogresslight(red/green)

 L3Pump‐outinprogresslight

 Norinse‐aidsymbol(ifasystemformonitoringoutsidethedishwasherisprovided)

 Tankheatingelementonsymbol

 Nosaltsymbol(ifsoftenerisfitted)

 Boilerelementonsymbol

 Nodetergentsymbol(ifasystemformonitoringoutsidethedishwasherisprovided)

