Smithco 45-204-C - Page 103

C-45
Rear Attachment
42-130Q 84" (213CM) MILD STEEL TOURNAMENT RAKE PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HSTP-516-18-100 Phillips Machine Screw,
5
/
16
- 18 x 1 16
HNFL-516-18 Flange Whiz-Loc Nut,
5
/
16
- 18 16
2 42-135 Finishing Blades 4
3 HSTP-516-18-075 Phillips Machine Screw,
5
/
16
- 18 x
3
/
4
8
HNFL-516-18 Flange Whiz-Loc Nut,
5
/
16
- 18 8
4 42-111 Left Outside Mount 1
5 42-102 Outside Rake 3
6 HRP-14-100 Roll Pin,
1
/
4
x 1 2
7 HMB-58-14 Machine Bushing,
5
/
8
x 14GA 4
8 HNC-14-20 Cap Nut,
1
/
4
- 20 2
HWL-14 Lock Washer,
1
/
4
2
9 43-144 Draw Bar 1
10 50-081 Rubber Bumper 2
11 42-110 Left Inside Mount 1
12 42-108 Inside Trowel Mount 1
13 HB-14-20-175 Hex Bolt,
1
/
4
- 20 x 1
3
/
4
1
HNTL-14-20 Nylon Lock Nut
1
/
4
- 20 1
14 HSTP-516-18-125 Phillips Machine Screw,
5
/
16
- 18 x 1
1
/
4
12
HNFL-516-18 Flange Whiz-Loc Nut,
5
/
16
- 18 12
15 42-109 Outside Towel Mount 1
16 42-105 Top Strap 4
17 42-106 Bottom Strap 4
18 42-122 Rake Spring 12
19 42-129 Groomer Blades 3
20 42-107 Matting 4
21 15-013 Rubber Bumper 2
22 42-177 Spring Holder 12
