3
Introduction
SAND STAR SPECIFICATIONS
WEIGHTS AND DIMENSIONS
Length 68" (1�73 m)
Width 58" (1�47 m)
Height 52" (1�2 m)
Wheel Base 42" (1�07m)
Ground Clearance 5�5" - 7" (13 -18 cm) - under cultivator depending on attachment
Weight 3WD - 915 lbs� ( 415 kg)
SOUND LEVEL (EAR PROTECTION REQUIRED)
At Ear Level 87 dB
ENGINE
Make Briggs and Stratton Vanguard
Model# 356447
Type / Spec# 0263 G
Horsepower 18 hp (13 kW)
Fuel Unleaded 87 Octane Gasoline Minimum
Lubrication System Full Pressure
Alternator 16 amp
WHEELS & TIRE Three: 22 X 11 - 10�0 Knobby Tires 5 psi (�34 bar)
Optional: 23-10�50 x 12 Turf Tires 5 psi (�34 bar)Smithco # 48-265
SPEED
Forward Speed 0 to 10 m�p�h� (0-16 kph)
Reverse Speed 0 to 5 m�p�h� (0-8 kph)
BATTERY Automotive Type SP 35
BCI Group Size 35
Cold Cranking Amps 300
Ground Terminal Polarity Negative (-)
Maximum Length 7�5" (19 cm)
Maximum Width 5" (12,7 cm)
Maximum Height 7�5" (19 cm)
FLUID CAPACITY
Crankcase Oil See Engine Manual
Fuel 20 quarts (18�93 liters)
Hydraulic Fluid 20 quarts (18�93 liters)
Grade of Hydraulic Fluid SAE 10W-40 API Service SJ or higher Motor Oil
ROPS CERTIFICATION
Rops ISO 21299
Seatbelts OSHA 1928�51
HYDRAULIC PRESSURES
Piston Pump Displacement �913 in
3
Charge Pump Displacement �33 in
3
/rev
Pump Input Speed (up to) 3300rpm Max� Inlet Vacuum 5 in� Hg
Max� Operating Pressure 3000 peak psi Max� Case Pressure 25 psi
Implement Setting 345 psi Relief Valve Pressure (set at) 1230 psi
13-729 Hydraulic Valve (2 bank) 900 psi
