Smithco 45-204-C - Roll Bars

53
Accessories
45-004 ROPS PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HB-716-14-100 Hex Bolt,
7
/
16
- 14 x 1 2
2 HNTL-716-14 Nylon Lock Nut,
7
/
16
- 14 8
3 HB-716-14-125 Hex Bolt,
7
/
16
- 14 x 1
1
/
4
6
4 45-082 Seat Belt Brace 1
5 76-198-03 Seat Belt 1
6 45-060 Roll Bar 1
7 HB-716-14-150 Hex Bolt,
7
/
16
- 14 x 1
1
/
2
2
INSTALLATION INSTRUCTIONS
The Following instructions apply to all Sand Star Machines�
1� Line up the mount plate on the roll bar to the square mounting plate by the seat� Mount vertically, not
leaning back toward the rear of the machine�
2� Place four 1
1
/
4
" bolts in the right mount plate holes and tighten� Place two 1
1
/
4
" bolts on left rear and two
1
1
/
2
" bolts on left front� Bolts are longer in the left front to accommodate remote air cleaner option�
  

4� Mount seat belts onto seat belt brace using 1" bolts� The strap goes on the right side and the lock goes
on the left side�
5� Tighten all hardware�
 ROPsarecertiedtomeetISO21299andrestraintsmeetOSHA1928.51
