11
Service
ADJUSTMENTS
SPEED BOSS
Speed Boss allows the machine to operate at
a proper speed while raking sand traps on golf
courses� This speed boss has been factory set at
an average speed of 3-4 m�p�h� (5-6�5 kph)� The
Speed Boss will only limit the speed while the
rake is lowered into the operating position� The
speed setting may be adjusted by turning the
Ball Joint (A) counterclockwise to make the ma-
chine operate slower or turn clockwise to go fast-
er� Tighten jam nut� Check to make sure nothing
is binding and test drive to check desired speed�
For RBS System, Spiker and Grader Box remove
the speed boss arm and the speed boss rod from
machine so it does not interfere with other opera-
tions�
STORAGE
When storing, remove the key from the key switch to avoid unauthorized persons from operating machine�
1� Before storing clean machine thoroughly�
2� Check bolts and nuts, tighten as necessary�
3� Make all repairs that are needed and remove any debris�
4� Remove the battery, adjust the electrolyte level and recharge it� Store the battery in a dry, dark place�
5� Store in a clean and dry area, but NOT near a stove, furnace or water heater which uses a pilot light or
any device that can create a spark�
6� Engines stored over 30 days need to be protected or drained of fuel to prevent gum from forming in a
fuel system or on essential carburetor parts� Check the engine manual and follow the instructions for
the storage of the engine�
