C-89
Rear Attachment
72" COCO MAT FINISHER PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 13-688 Brush Channel 1
HB-14-20-075 Hex Bolt,
1
/
4
- 20 x
3
/
4
2
HNFL-14-20 Flange Whiz-Loc Nut,
1
/
4
- 20 2
2 43-168 Brush Mount Arm 2
HB-14-20-075 Hex Bolt,
1
/
4
- 20 x
3
/
4
6
HNFL-14-20 Flange Whiz-Loc Nut,
1
/
4
- 20 6
3 13-683 Brush Track 1
4 13-682 Brush, 77 x 11 1
5 43-164 Adjustment Handle 1
6 43-166 Mat Clamp 4
HB-38-16-125 Hex Bolt,
3
/
8
- 16 x 1
1
/
4
8
HNFL-38-16 Flange Whiz-Loc Nut,
3
/
8
- 16 x 1
1
/
4
8
7 43-165 Frame 1
8 43-167 Coco Mat, 27 x 72 1
9 43-162 Draw Bar 1
HHP-18 Bridge Pin,
1
/
8
1
10 43-163 Lock Handle 1
11 HCP-12-300 Clevis Pin,
1
/
2
x 3 1
HHP-18 Bridge Pin,
1
/
8
1
Some components of your Coco Mat Finisher have been assembled at the factory for your convenience�
1� Start by mounting the Draw bar (Ref 9) to the Frame (Ref 7) using the Clevis Pin and Bridge Pin (Ref
11)� Position the Draw bar, using either set of holes, as illustrated�
2� Next, mount the Brush assembly (Ref 1, 3 & 4) to the Brush Mount Arms (Ref 2), as illustrated, using
the (6)
1
/
4
- 20 x
3
/
4
Hex Bolts and
1
/
4
- 20 Flange Whiz-Loc Nuts� Secure fasteners tight�
3� The holes on each of the Brush Mount Arms will line up� Mount to the pin on the Draw bar (Ref 9) and
secure using the remaining Bridge Pin�
4� Thread the Lock Handle (Ref 10) on to the Adjustment Handle (Ref 5)� Thread the Adjustment Handle
into the nut on top of the Draw bar (Ref 9), continuing until the threaded rod is through the Draw bar
tube� Turn the Lock Handle clockwise () to lock the Adjustment handle in place�
Adjusting the Coco Mat Finisher
󰀨Finisher
Finisher's leading edge angle�
1� Release the Lock Handle (Ref 10) by holding the Adjustment Handle (Ref 5) and turning the Lock Han-
dle counterclockwise ()�
2� To raise the leading edge (front) of the Finisher, turn the Adjustment Handle clockwise ()� When you
obtain your desired position, turn the Lock Handle clockwise () to lock the Adjustment handle in place�
3� To lower the leading edge (front) of the Finisher, turn the Adjustment Handle counterclockwise ()�
When you obtain your desired position, turn the Lock Handle clockwise () to lock the Adjustment han-
dle in place�
