Smithco 45-204-C - Center Lift

40
Parts
CENTER LIFT DRAWING
REF# PART # DESCRIPTION QUANTITY
1 18-168 90° Elbow 2
2 HHP-18 Bridge Pin,
1
/
8
1
3 HCP-58-150 Clevis Pin,
5
/
8
- 1
1
/
2
1
4 10-554 Hydraulic Cylinder 1
14-529 Seal Kit 1
5 HNJ-58-18 Jam Nut,
5
/
8
- 18 1
6 18-154 Rod End 1
HG-14-28-180 Grease Fitting,
1
/
4
- 28 x 180° 1
7 45-153 Center Ram Holder 1
