Smithco 45-204-C - Nail Scarifier

B-35
Center Attachment
45-177 NAIL SCARIFIER WITH CASTOR WHEELS PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HCP-12-200 Clevis Pin, ½ x 2 2
HHP-18 Bridge Pin,
1
/
8
2
    
10-025 Flange Bushing (Part of 43-171) 4
HG-14-28-180 Grease Fitting,
1
/
4
- 28 x 180° (Part of 43-171) 2
3 HMB-34-14 Machine Bushing, ¾ x 14GA 2
4 42-215 Short Spacer 2
5 42-214 Long Spacer 2
6 42-539 Lynch Pin, ¼” 2
7 HMB-34-10 Machine Bushing, ¾ x 10GA 12
8 42-204 Castor Fork 2
9 42-202 Tire & Wheel 2
10 33-338 Axle Bearing 2
11 HB-12-13-600 Hex Bolt, ½ - 13 x 6 2
HNTL-12-13 Nylon Lock Nut, ½ - 13 2
12 HSSQS-38-16-150 SS Sq� Head Set Screw,
3
/
8
- 16 x 1½ 4
HN-38-16 Hex Nut,
3
/
8
- 16 4
13 45-172 Nail Channel Cover 1
14 45-170 Nail Plate 1
15 9028 Spiral Shank Nail, 7GA x 4" 57
16 HCP-14-075 Clevis Pin, ¼ x ¾ 1
HP-332-075 Cotter Pin,
3
/
8
x ¾ 1
17 45-169 Nail Channel 1
18 43-175 Compression Spring 4
19 HCP-58-200 Clevis Pin,
5
/
8
x 2 1
HHP-18 Bridge Pin,
1
/
8
1
