C-83
Rear Attachment
42-581 GREEN STAR RBS ROLLER SET (3) PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 42-574 Fork 3
2 18-295 Oilite Bushing (part of 42-574) 6
3 HB-38-16-150 Hex Bolt,
3
/
8
- 16 x 1
1
/
2
12
HWL-38 Lock Washer,
3
/
8
12
HW-38 Flat Washer,
3
/
8
12
HN-38-16 Hex Nut,
3
/
8
- 16 12
4 11-094 Pillow Block 6
5 42-584 Roller 3
6 42-539 Lynch Pin,
5
/
16
(part of main frame) 3
7 42-586Q Green Star RBS Main Frame 1
ADJUSTMENTS AND OPERATION INSTRUCTIONS
ADJUSTMENT
The springs are preset for maximum down pressure, and should not need to be adjusted� If you feel the need
to adjust the springs please call for further instructions� The unit comes pre-adjusted for most models� The
four adjustment holes on the hitch are for making sure all three rollers are touching the ground at the same
pressure� When installing roller system start with the lower mounting holes on hitch�
Tire pressure should be 4 psi in the front and 7 psi in the rear tire for best traction�
OPERATION
Make sure the rolling system has been installed and adjusted properly for your model of bunker rake� Always
rolling� Do not roll up steep slopes or loss of traction may result� Do not turn while rolling�
To begin rolling, lower unit all the way down as you come across collar and continue straight across green un-
