C-85
Rear Attachment
42-585 GREEN STAR RBS BRUSH SET (3) PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 42-539 Lynch Pin,
5
/
16
(part of main frame) 4
2 18-295 Oilite Bushing (part of 42-579) 6
3 HSPP-516-18-075 Phillip Head Screw,
5
/
16
- 18 x
3
/
4
6
4 42-579 Brush Bracket 3
5 42-545 Brush Head 3
6 42-586Q Green Star RBS Main Frame 1
ADJUSTMENTS AND OPERATION INSTRUCTIONS
ADJUSTMENT
The springs are preset for maximum down pressure, and should not need to be adjusted� If you feel the need
to adjust the springs please call for further instructions� The unit comes pre-adjusted for most models� The
four adjustment holes on the hitch are for making sure all three brushes are touching the ground at the same
pressure� When installing brush system start with the lower mounting holes on hitch�
Tire pressure should be 4 psi in the front and 7 psi in the rear tire for best traction�
OPERATION
Make sure the brush system has been installed and adjusted properly for your model of bunker rake� Always
brushing� Do not brush up steep slopes or loss of traction may result� Do not turn while brushing�
For drag brushes use hydraulics to control the amount of down pressure required to move your top dressing
material� We recommend reversing drag brushes after each use for even wear� To begin brushing, lower unit
as you come across collar and continue straight across green until reaching other collar and raise as you
