C-97
Rear Attachment
INSTRUCTIONS
READ ENGINE MANUAL PRIOR TO STARTING THIS MACHINE�
Machine is shipped with NO OIL in engine�
Fill Engine with oil as suggested in Engine Manual�
1� You must prime pump before starting the engine� To do so, insert garden hose in Discharge Tube and
2� Fill engine up with 4-stroke motor oil as advised in the engine manual�
3� Install a U-1 300 Amp Battery into the battery box on the right side of the engine� Connect battery ca-
bles and strap battery into place�
4� Make yourself familiar with engine controls located on the engine by reading the Engine Owner's Manu-
al�
the Super Star Bunker Rake�
6� The Typhoon is equipped with a quick hitch attachment� Insert quick hitch bar into hitch on Super Star
and lock in place with lock pin�
7� There are 1/2" and 1" spacers on the castor wheels that can be arranged in any combination to achieve
the desired height� Please keep both side adjusted the same�
8� Transport the Typhoon to the water hole that needs to be siphoned� Back Typhoon to edge of water�
9� Using the rocker switch on the left side of the engine, lower the boom and suction screen into the wa-
ter�
10� Stand clear of the discharge tube� Make sure the discharge tube is pointing in a direction that is free of
bystanders and buildings�
11� Start engine� There will be immediate water discharge from the discharge tube� There is a swivel tube
that allows you to turn the discharge in any direction you desire� There is also a turnbuckle that can be
discharge tube to prevent it from straying�
run the pump dry�
DO NOT RUN THE PUMP DRY!
13� Using the rocker switch, raise boom out of the water hole�
